Copper Foam Electrode Substrate for Battery and Supercapacitor Applications

Copper Foam Electrode Substrate for Battery and Supercapacitor Applications

$69.00 USD
$69.00 USD
Sale Sold out
Shipping calculated at checkout.

LA019-5

Size(T*W*L)
  • Formal Quotes & POs
  • DDP to Most Destinations
  • Return Policy Available

Product Description

Copper foam is a highly porous conductive material widely used as an electrode substrate in battery and supercapacitor research. Its three-dimensional network structure provides a large surface area, enabling efficient electron transport and enhanced electrochemical performance.

This material is particularly suitable for applications requiring high conductivity and structural support, such as lithium-ion batteries, zinc-based batteries, and supercapacitors.

With uniform pore distribution and excellent mechanical stability, copper foam supports active material loading and improves overall electrode efficiency in laboratory research environments.

Specifications

Parameter Specification
Material Copper (Cu)
Purity ≥99.9%
Porosity above 90%
Pore Density 130 PPI (pores per inch)
Thickness 0.1 – 20 mm
Conductivity High-conductivity copper structure

Applications

  • Battery electrode substrate (anode/cathode support)
  • Supercapacitor electrode fabrication
  • Lithium-ion and sodium-ion battery research
  • Zinc-based and aqueous battery systems
  • Electrochemical catalyst support
  • Energy storage material development

Technical Data Sheet

Download TDS

Provided for product selection and research reference. This document is not an SDS.
