CR2032 / CR2025 / CR2016 / CR2430 Coin Cell Case (SS304) – 2-Piece Set

CR2032 / CR2025 / CR2016 / CR2430 Coin Cell Case (SS304) – 2-Piece Set

$49.00 USD
$49.00 USD
Sale Sold out
Shipping calculated at checkout.

LA007-2

Type
Quantity
  • Formal Quotes & POs
  • DDP to Most Destinations
  • Return Policy Available

Product Overview

The CR20XX coin cell case (2-piece set) is a standard laboratory component used for assembling coin cells for battery research and material evaluation. Each set includes a cathode case and an anode case with a sealing gasket, manufactured from high-quality stainless steel 304 (SS304) to ensure excellent corrosion resistance and mechanical stability.

These coin cell cases are widely used in lithium-ion, sodium-ion, lithium-sulfur, and other advanced battery research. They are compatible with most coin cell crimping machines used in laboratory environments.

Specifications

Type Component Top Diameter Inner Diameter Height Thickness
CR2016 Cathode Case 19.95 mm 19.55 mm 1.6 mm 0.20 mm
Anode Case 18.7 mm 17.6 mm 1.0 mm 0.20 mm
CR2025 Cathode Case 19.95 mm 19.45 mm 2.3 mm 0.25 mm
Anode Case 18.7 mm 18.7 mm 1.7 mm 0.25 mm
CR2032 Cathode Case 19.95 mm 19.45 mm 2.85 mm 0.25 mm
Anode Case 18.6 mm 17.2 mm 2.25 mm 0.25 mm
CR2430 Cathode Case 24.45 mm 23.8 mm 2.9 mm 0.25 mm
Anode Case 22.9 mm 20.9 mm 2.2 mm 0.25 mm
